| Form Factor (Midi, Micro, Mini , Full) | Mid Tower | |
| Chassis | SPCC:0.4mm | |
| PSU Form Factor | Bottom/ATX | |
| M/B Form Factor | ATX、M-ATX、ITX | |
| Front Panel | ABS | |
| Top Panel | metal cover | |
| Side Panel | Left | Tempered Glass |
| Right | metal cover | |
| External Drive Bay(s) | 5.25″ (ODD) | / |
| 3.5″ | / | |
| Internal Drive Bay(s) | 3.5″ (HDD) | 1*3.5HDD+5*2.5SSD or 2*3.5HDD+3*2.5SSD or 3*3.5HDD+2*2.5SSD or 2*3.5HDD+2*2.5SSD |
| 2.5″ (SSD) | ||
| I/O | Buttons | *2 |
| USB2.0 Port(s) | *1 | |
| USB3.0 Port(s) | *1 | |
| HD Audio Support | Combo Audio(CTIA)*1 | |
| Type C | *1(2.0 or GEN1 or GEN2) | |
| P-Lock | *1 (optional) | |
| RGB Controller | *0 | |
| Controller max. fans | *0 | |
| RGB Controller max. LED strips | *0 | |
| Remote (IR or RF) | *0 | |
| Cooling Fan Support | Front | 3x120mm |
| Top | 2x120mm ,2x140mm (Fan optional) | |
| Rear | 1x120mm | |
| Left Side | / | |
| PSU Cover | 2x120mm (Fan optional) | |
| Water Cooling Support (Radiator Size) |
Front | 120mm, 240mm,360mm |
| Top | 120mm, 240mm(RAM Height ≤30mm) | |
| Rear | 120mm*1 | |
| Dust Cover | Bottom and top cover with dust filter | |
| Slots | *7 | |
| Carton & Logo | GAMEMAX | |
| Dimensions | Chassis | (L)340*(W)200*(H)436mm |
| Full Case (inc Fascia) | (L)386*(W)200*(H)449mm | |
| Carton | (L)486*(W)255*(H)456mm | |
| Net Weight (Kg) | 3.5kgs | |
| Gross Weight (Kg) | 4.3kgs | |
| VGA Card Length | up to 330mm | |
| CPU Cooler Height | 155mm | |
| PSU Length | up to 160mm | |
| Cable Management Depth | 19mm | |
