- Form factor: M.2 2280
- Host Interface: Serial ATA Interface 6.0 Gbps
- Operating Temperature: 0°C to 70°C
- Non-Operating Temperature: -40°C to 85°C
- Humidity: 5% to 95%, non-condensing
- Shock: 1500G, duration 0.5ms Half Sine Pulse
- Vibration: 7Hz~800Hz, 3.08Grms, 30 min/axis (X,Y,Z)
- Dimensions: 80mm x 22.1mm x 2.3mm
- Weight: 9.1g
Data Transfer:
- Read Speeds: 512GB: up to 520MB/s*
- Write Speeds: 512GB: up to 480MB/s*
Power Consumption:
- Active Read Power Consumption: 512GB: 1430mW
- Active Write Power Consumption: 512GB: 1390mW
- Idle Power Consumption: 512GB: 600mW
