| Specification | |
| Tip | Standard power supply |
| Oblik (Form factor) | ATX12V |
| Output power | 650W |
| PFC (Power Factor Correction) | Active PFC |
| Connectors | 1 x 20+4-pin 1 x CPU(4+4pin) 2 x PCIe (6+2pin) 6 x SATA 2 x Molex |
| 20+4 pin | 1 |
| 8(4+4)pin EPS 12V | 1 |
| PCI-e 6+2 Pin | 2 |
| HOURS | 6 |
| Molex 4 pin | 2 |
| Power supply specifications | +12V: 54A +3.3V: 15A +5V: 15A -12V: 0.3A +5Vsb: 2.5A |
| +3.3V | 15.4A |
| +5V | 15A |
| +12V | 54 A |
| -12V | 0.3A |
| +5Vsb | 2.5A |
| Power protection | OVP (Over Voltage Protection) – turns off the power supply when the voltage is too high UVP (Under Voltage Protection) – turns off the power supply when the voltage is too low OPP (Over Power Protection) – protects when the total load exceeds the permitted power SCP (Short-Circuit Protection) – turns off the power supply in the event of a short circuit SIP (Surge & Inrush Protection) – protection against overvoltage and initial current surge |
| Fan diameter | 12cm |
| Dimensions | 150 x 140 x 85 mm |
| Cooling | Active (with fan) |
| EAN | 3856032100938 |
| Guarantee | |
| Complaint period | 36 months |
