ENGINEERED FOR MODERN COMPONENTS
With the ability to provide twice the total system power, 2.5 times the 12V CEM peak power, and three times the rated power of the 12V-2×6 cable for 0.1 ms, random power spikes will never be an issue. The PQ850G will provide stable and consistent power for legacy and modern power-hungry PCs for the foreseeable future.
PCI-E 5.1 PERFECTION
Equipped with a high-grade sleeved 105C-resistant 16AWG copper-core 12V-2×6 cable, the PQ850G provides up to 600W for modern GPUs.
Technical Spec
Total Output : 850W
Type : ATX12V V3.1
Product Dimensions : 150×140×86mm (W x L x H)
Efficiency certification : 80Plus Gold/Cybenetics PLATINUM/PPLP Gold
Fan Size : 120×120×25mm (W x L x H)
Fan Bearing : FDB (Fluid Dynamic Bearing)
Topology : Active PFC + Half Bridge SRC LLC + DC to DC
Capacitors : Full Japanese Electrolytic Capacitors
Power Good Signal : 100-150ms
Hold Up Time : ≥16ms Full load
Efficiency : ≥90% Under Typical Load(50% Loading)
Protection : OPP/OVP/SCP/OTP/OCP/UVP/SIP/NLO
Operation Temperature : 0-40°C
Regulatory : EAC
Erp Regulation : ErP 2013
Environment Protection : EAC
MTBF : 100,000 Hours
