FUTURE PROOF
With the ability to provide three times the TGP for 0.1 ms, random power spikes will never be an issue. The PN1000D will provide stable and consistent power for legacy and next-generation PCs for the foreseeable future.
GRACEFUL GOLD
80 Plus Gold certified to meet a high level of power efficiency under 90% of typical loads. Each unit is also rated Gold by Cybenetics.
PCI-E 5.1 POWER
Equipped with a high-grade 105C-resistant 16AWG copper-core sleeved 12V-2×6 cable, the PN1000D provides up to 600W for modern GPUs.
Technical Spec
Type: ATX12V V3.1
Product Dimensions: 150×140×86mm (W x L x H)
Efficiency certification: 80Plus Gold/Cybenetics Gold
Fan Size: 120mm
Fan Bearing: HYB(Hydro Bearing)
Topology: Active PFC + Full Bridge SRC LLC + DC to DC
Capacitors: Chinese Electrolytic Capacitors
Power Good Signal: 100-150ms
Hold Up Time: ≥16ms(80% Load)
Efficiency: ≥90% Under Typical Load(50% Loading)
Protection: OPP/OVP/SCP/OTP/OCP/UVP/SIP/NLO
Operation Temperature: 0 – 40℃
Regulatory: CE/CCC/TUV-RH/RCM
Erp Regulation: ErP 2014
Environment Protection: WEEE/中国 RoHS/Triman
MTBF: 100,000 Hours
